LPKF ProtoPlace S Semiautomatic SMT Pick & Place Assembly Unit

The LPKF ProtoPlace S is an ergonomically designed, semi-automatic pick & place system for the professional assembly of SMT printed circuit board prototypes and small batch projects. The ProtoPlace S quickly assembles SMT boards, with the user controlling each step of the assembly process through an LCD display. Most functions are easily executed from an interface panel with four directional arrows.

Precise fine-pitch component assembly. With ProtoPlace S it is possible to place various components including fine-pitch down to 0,4 mm (16 mil). Precise placing of fine-pitch components is ensured by a x/y/z locking mechanism, micro table fine adjustment and automated placing. Final placement is done automatically thus eliminating operator errors.

Includes Optional Micro camera for greater control and precision. The micro camera can be easily installed onto the system, providing greater control and accuracy. The camera is tilted for a side view of the components giving the operator a very clear view of the placement area.

Includes Optional Motorized turntable. A great advantage of the ProtoPlace S system is its motorized turntable which contains antistatic bins for loose components. Table cover opens only one bin at a time.

Also include five tape feeder modules shown in the photos.

Maximum circuit board size 297 × 420 mm (11.8” × 16.5”)

115V, 50/60Hz, 10A
